This study aims to optimize the process conditions for high-density polyethylene (HDPE) additive manufacturing through a systematic analysis of key variables, including material selection, layer height, feed rate, melting temperature, and bed temperature. By exercising precise control over these variables, optimal conditions were established, which included a melting temperature of 240oC, a welding speed of 150 cm/min, and a material throughput of 5.66 kg/h. Furthermore, the process was refined by implementing a zig-zag layering method, which significantly improved the stability, bonding strength, and overall mechanical properties of the final HDPE products. The effects of these optimized process conditions were assessed through a series of mechanical tests, such as tensile tests, impact tests, and heat deflection temperature (HDT) tests. As a result, the defined process conditions yielded excellent mechanical performance, achieving a tensile strength of 21.15 MPa, an impact strength of 320 J/m, and an HDT of 93oC. Overall, this study illustrates the enhancement of HDPE additive manufacturing quality through the optimization of process conditions. The strategic implementation of these optimized variables, along with advanced extrusion module design, demonstrates the potential for producing high-quality and cost-effective HDPE products, thereby underscoring their enhanced marketability and performance potential.
Additive manufacturing, a key enabler of Industry 4.0, is revolutionizing the automatic landscape in manufacturing. The primary challenge in manufacturing innovation centers on the implementation of smart factories characterized by unmanned production facilities and automated management systems. To overcome this challenge, the adoption of 3D printing technologies, which offer significant advantages in standardizing production processes, is crucial. However, a major obstacle in complete automation of additive manufacturing is an inadequate placement of support structures at critical locations, which remains the leading cause of print failures. This study proposed a novel algorithm for accurate detection of island regions known to be critical areas requiring support structures. The algorithm can compare loops on two consecutive layers derived from STL files. In contrast to conventional GPU-based image comparison methods, our proposed CPU-based algorithm enables high-precision detection independent of image resolution. Experimental results demonstrated the algorithm's efficacy in enhancing the reliability of 3D printing processes and optimizing automated workflows. This research contributes to the advancement of smart manufacturing by addressing a critical challenge in the automation of additive manufacturing processes.
Additive manufacturing (AM) technology, also known as 3D printing, is a highly promising technology that can drive innovation in various industrial areas, including the nuclear industry. Although the nuclear industry is traditionally conservative when it comes to adopting new technologies, it is crucial that AM technology is eventually applied for a variety of reasons. To overcome the barriers that currently hinder the adoption of AM in the nuclear industry, it is essential to ensure the reliability of AM products. One key factor is ensuring that AM products have mechanical properties equivalent to those of traditionally manufactured products. This paper presents the results of mechanical property tests conducted on additive manufactured specimens of stainless steel 316 L after heat treatment. We performed tensile tests, hardness tests, and microstructure analysis on specimens produced using two types of metal AM technologies: powder bed fusion (PBF) and directed energy deposition (DED). The results of the tests indicate that certain weaknesses, such as anisotropy and brittleness, in AM products can be improved through three types of heat treatments. In particular, AM products produced using the PBF method and subjected to heat treatments show potential for application in the nuclear industry in terms of materials.
Recent advancements in additive manufacturing (AM) have made it possible to create compact heat exchangers (HXs) with complex geometries. This study introduces a new approach that uses Triply Periodic Minimal Surface (TPMS)-based designs for HXs. Mathematical filtering techniques are incorporated to optimize the local morphology changes. The goal of the proposed mathematical filtering method is to improve the flow characteristics and heat exchange capability of TPMS HXs by modifying the structure’s morphology at the inlet and outlet regions. This modification facilitates flow selection and reduces pressure drop. The HX design includes cylindrical flow domains at the inlet and outlet regions. Three different HX designs with varying inlet/outlet domains (through-hole, half-hole, and taper-hole) were fabricated using polymer AM and DLP 3D printing. These designs were then tested for pressure drop. Among the three designs, the taper-hole configuration showed the best flow characteristics, with a 50% reduction in pressure drop compared to previous studies. The taper-hole design was then replicated using metal AM technology, resulting in a 70-125% improvement in heat exchange capacity compared to previous studies.
Citations
Citations to this article as recorded by
Multifunctional gradations of TPMS architected heat exchanger for enhancements in flow and heat exchange performances Seo-Hyeon Oh, Jeong Eun Kim, Chan Hui Jang, Jungwoo Kim, Chang Yong Park, Keun Park Scientific Reports.2025;[Epub] CrossRef
During its early development stages, 3D printing was primarily used for rapid prototyping, whereas it is currently employed to fabricate products in various fields, including aerospace, automobile production, dentistry, architecture, and food. The photopolymerization of the polymer used for 3D printing is precise and provides excellent surface roughness but has lower mechanical strength than traditional manufacturing methods. In this study, Multi-walled Carbon Nanotubes (MWCNTs) were blended with urethane acrylate-based resin as a filler. Mechanical strength enhancement was confirmed using a DLP 3D printer. The stabilities of MWCNT dispersions in resin were verified, and viscosity and curing depth measurements were conducted to establish 3D printing parameters. Tensile and flexural strengths were higher for an MWCNT length of 50 μm than one of 100 μm, and maximum values were obtained at an MWCNT content of 0.1 phr. Under optimal conditions, tensile and flexural strengths increased by 2.1 and 1.8-fold, respectively.
In this study, we present the fabrication of dual-morphing vascular stents using an additive-lathe printing method and two different shape-memory polymers. Traditional additive manufacturing techniques confront significant challenges in producing vascular stents with complex, hollow, mesh-like structures due to limitations such as a flat printing bed and the placement of supports. To overcome these obstacles, we employed a lathe-type additive manufacturing system with a rotatable base substrate, enabling precise fabrication of cylindrical-shaped stents. To achieve shape transformability, we used shapememory polymers as the stent materials, offering the advantage of minimally invasive surgery. Two distinct shape-memory polymers, with different transition temperatures (35 and 55oC), were printed using the additive-lathe method. The printed stents consisted of two distinct parts that underwent dual-stage morphological changes at the different temperatures. By manipulating the printing paths, the dual-morphing properties of the stents could be adjusted in both longitudinal and circumferential directions. This innovative approach could be a solution to several limitations associated with the application of stents in diseased vascular tissues with complex shapes, facilitating minimal invasion during surgical procedures.
In this study, the design for additive manufacturing of shoe molds with complex and precise patterns was performed to achieve rapid prototyping. Low alloy steels such as AISI4340 and SAE1524 were selected to make shoe molds to apply to the conventional chemical etching process. A lattice-oriented design and optimization of toolpath was tested to reduce the processing time. A reduction of 60% in processing time and pattern precision of 0.3 ㎜ was been achieved. Moreover, to improve the reliability of pattern formation, single-layer image analysis with computer vision and machine learning was developed and non-destructive analysis by X-ray CT was been performed. It was found that the quality of shoe molds can be decreased with a single defective layer.
In this paper, when the finishing process is performed on the additive by FDM type, the optimal parameter set of the additive-finishing design parameters to improve the surface quality and the verification of the finishing effect are described. Additive design parameters such as nozzle diameter and layer height and finishing design parameters such as depth of cut and feed rate have a significant influence on the printing time and surface roughness of the sculpture. So, we define the major additive-finishing design parameters expected to affect the results. So, we define the major additive-finishing design variables that expected to affect the experimental results. And to confirm how much they affect the results with the minimum number of experiments, the sensitivity analysis of the design parameters was performed through the level average analysis of the Taguchi method. As a result, compared to the surface roughness and additive time when only high-quality sculpture was performed, and it was confirmed that the printing time improved up to 70% and the surface roughness improved up to 87% for the additive-finishing sculpture performed with the optimal combination of design parameters.
Citations
Citations to this article as recorded by
Advancements in polymer nanocomposite manufacturing: revolutionizing medical breakthroughs via additive manufacturing Sadaf Bashir Khan, Shenggui Chen, Xiaohong Sun Polymer Bulletin.2024; 81(11): 9465. CrossRef
Optimal Joint Path Planning of a New Virtual-Linkage-Based Redundant Finishing Stage for Additive-Finishing Integrated Manufacturing Jiwon Yu, Haneul Jeon, Hyungjin Jeong, Donghun Lee Mathematics.2023; 11(24): 4995. CrossRef
Recently, industrial manufacturing has developed into additive manufacturing, benefiting from multi-item small-sized production and effective manufacturing. Importantly, Wire Arc Additive Manufacturing, which uses metal wires, is attracting worldwide attention for its high-quality metal product technology. Technological innovation that combines virtual physics with reality through big data communication, such as process variables along with Wire Arc Additive Manufacturing, is an essential task for implementing smart manufacturing technology. Due to the characteristic of Wire Arc Additive Manufacturing, numerous variable conditions exist, making it difficult to standardize robot"s process path data generation algorithms and data application methods, and this data generation method is being studied as a core element technology. The present study generated foundation process implementation, simulation, and generated path data for robots in virtual space using RoboDK, which provides robot libraries from multiple manufacturers, and Python, which is a universal programming language. To implement the experimental data in practice, ABB"s industrial six-axis robots IRB-6700 and Fronius TPS500i were used to control the arcing plasma heat source, and the process path worked the same as simulation. Based on the underlying experimental results, this process can be applied to generation of additive manufacturing in the Wire Arc Additive Manufacturing process for 3D models.
Citations
Citations to this article as recorded by
Artificial Intelligence Technologies and Applications in Additive Manufacturing Selim Ahamed Shah, In Hwan Lee, Hochan Kim International Journal of Precision Engineering and Manufacturing.2025; 26(9): 2463. CrossRef
In-situ remanufacturing of forging dies for automobile parts based on wire arc directed energy deposition Chang Jong Kim, Chan Kyu Kim, Hui-Jun Yi, Seok Kim, Young Tae Cho Journal of Mechanical Science and Technology.2024; 38(9): 4529. CrossRef
Additive manufacturing requires a relatively long time to fabricate complex three-dimensional (3D) structures or parts with more than one material. For additive manufacturing processes, production time and precision vary depending on the fabrication conditions. In this study, we developed a food additive manufacturing process of the material extrusion method type using a dual nozzle. In addition, we observed the change in the cross-sectional shape of the discharged food line according to each fabrication condition. By using a dual nozzle, the structure was fabricated under conditions of relatively high precision for the outer wall and relatively low precision for the infill, thereby shortening the production time. Through this process, it can be expected that the production time will be shortened in the food field, while the appearance will be of good quality.
Research on the application of additively manufactured polymer (AMP) to the conventional manufacturing process is underway. In this study, an additively manufactured die-set (AMDS) was used and applied to the warm forming of the magnesium alloy. Heat transfer and coupled temperature-displacement analysis were conducted in the V-Bending and UBending processes to study the applicability of the AMDS to the warm-forming process of the magnesium alloy sheet (AZ31B). A heat transfer experiment was conducted to determine the thermal contact conductance between the AZ31B material and two types of die-set, the metal and AMP. V-Bending and U-Bending experiments were conducted at 373 and 423 K; reduction in temperature between metal die-set and the additively manufactured polymer die-set were compared. The springback after the bending process with different initial temperatures and die materials was investigated. The simulation model showed good agreement. The springback of AZ31B was more decreased with the additively manufactured polymer die-set than with the metal die-set. The stress of the additively manufactured polymer die-set in the bending process was very small. It was confirmed that in the AZ31B material, the additively manufactured polymer die set helps increase the formability and decrease springback by keeping the temperature of AZ31B better.
Recently, competition in the manufacturing industry related to the preoccupation of new markets has drastically changed due to the increase in small quantity batch production products. Besides, business models utilizing 3D printing technology suitable for flexible manufacturing are gaining interest. As 3D printing technology is becoming more common, Design for Additive Manufacturing is also in the spotlight. However, the productivity of 3D printing technology is still insufficient in terms of mass production. In this study, the possibility of innovation in mass production process that combines 3D printing technology is presented through the case of innovation in manufacturing productivity of medium-speed engine cylinder head through the integration of sand 3D printing technology. It outlines how sand 3D printing technology is applied to cylinder head mass production processes, how the quality of cylinder head products can be improved compared to conventional pattern-based molding methods, and how productivity can be maximized by reducing process time and human error through hybrid production method with sand 3D printed integrated design cores. In conclusion, this paper presents the effectiveness of sand 3D printing technology which can secure product competitiveness by increasing the production capacity of mass production process, reducing production costs, improving quality, and reducing loss.
Citations
Citations to this article as recorded by
Digital Transformation of Metal Casting Process Using Sand 3D Printing Technology with a Novel Methodology of Casting Design Inside a Core Kuk-Hyun Han, Jin-Wook Baek, Tae Wan Lim, Ju Min Park International Journal of Metalcasting.2023; 17(4): 2674. CrossRef
Nature-inspired architected materials have been widely used to achieve efficient structural materials by harnessing their cellular and hierarchical structures. For example, biological materials observed in bone, shell, nacre, and wood contain constituents, ranging from nanometers to centimeters, arranged in an ordered hierarchy. Because of their composited structures that contain micro and nanoscale building blocks arranged in an ordered hierarchy and the material size effect in the mechanical strength of nano-sized solids, bioceramic materials are mechanically robust and lightweight. The design principles offered by hard biological materials of multiscale composite structures can assist in the creation of advanced ceramic architectures. In addition, the evolution of additive manufacturing technologies has enabled the fabrication of materials with intricate cellular architected materials. In this review, we discussed advanced additive manufacturing for the fabrication of nature-inspired multiscale ceramic structures by combining conformal thin-film coating technique with conventional additive manufacturing methods.
Citations
Citations to this article as recorded by
SEM Image Quality Improvement and MTF Measurement Technique for Image Quality Evaluation Using Convolutional Neural Network Chan Ki Kim, Eung Chang Lee, Joong Bae Kim, Jinsung Rho Journal of the Korean Society for Precision Engineering.2023; 40(4): 275. CrossRef
In this study, design for additive manufacturing (DfAM) of release agent injection manifold for hot forging has been performed to achieve weight reduction and flow path optimization. The weight reduction of 53.5% was achieved, thereby enabling the application of stainless steel 316L, which has high strength and corrosion resistance. Lightweight manifolds using Al-Mg-10Si and SUS316L materials were fabricated by PBF-type metal 3D printer. The feasibility test showed that mold life was improved by 14% by solving residual release agent problem. In addition, the flow path optimization results suggested that the flow standard deviation of each outlet dropped sharply from 264 to 75 ㎤/s. This approach demonstrated that DfAM for release agent manifold could be applied to increase mold life and improve product quality and productivity for hot forging.
Citations
Citations to this article as recorded by
Optimize Design of Flow Divider and Verification of the PBF 3D Printing Process Jae-Hwi Lee, Jae-Ho Shim, Dong-Hun Sin, Yong-Seok Yang, Dong Soo Kim Journal of Flexible and Printed Electronics.2024; 3(2): 249. CrossRef
Additive Manufacturing for Rapid and Precise Pattern Formation in Shoes Mold Seok-Rok Lee, Eun-Ah Kim, Ye-Rim Kim, Dalgyun Kim, Sunjoo Kim, Soonho Won, Hak-Sung Lee Journal of the Korean Society for Precision Engineering.2023; 40(3): 211. CrossRef
With the development of Additive Manufacturing process, lattice structures have recently been fabricated with fine quality. Lattice structures have unique performances which encompass various elastic responses. In this study, shear characteristics of the lattice structures (BCC and OTC) fabricated by SLM process, under optimized manufacturing conditions, were analyzed by 1/4 compression tests. As a result, several fracture modes and elastic configurations were found by comparing the compression test results of various lattice structures. In addition, the lattice structures possessed certain shear elasticity and normal elasticity among different types of lattices at elastic region when shearing. As the 1/4 compression test was simulating the lattice structure on concentrate load or shearing load, the test represented shock introspection characteristics of the lattice inner structure.
